Clipper Eclipse 324 Seed Cleaner

The Clipper Eclipse is the first in a line of small cleaners designed to meet the low maintenance and easy cleanout requirements of today’s seedsman. The Eclipse is built with the same care and craftsmanship as Clipper’s larger precision cleaners.

Unit has 2 flow pattern options: scalp, scalp, sift or scalp, split, sift.

Soybeans, Wheat, Corn –

*80 BPH (fast clean)

*55 BPH (precision clean)

Rice, Oats –

*60 BPH (fast clean)

*35 BPH (precision clean)

*Note: capacities may vary depending on seed condition, moisture content, seed varieties, types, and volumes of contaminants to be separated and the percentage of foreign material acceptable in the final product. Capacities also vary depending on product flow through the cleaner. Capacities shown above are for the split flow arrangement.

Standard Features:

Tubular Steel Frame

Inlet Feed Hopper

Heavy Duty 1-1/2″ Eccentric Shaft, Drive and Counterbalance

Scotch-Ply Shoe Hangers

3 Screens 24-1/2″ x 22-1/4″ Flows included: scalp, scalp, sift or scalp, split-sift

Ball Tray Screen Cleaning

Adjustable Bottom Air – Bottom Cleanout Air Door

1 Hp, 60 Hz, 1800 RPM, TEFC, 1 Phase 115/230 Volt Motor And Drive
